How do angle type control valves work?
The valve regulates flow by lifting a plug off a seat, similar to a globe valve, but redirects the flow at a right angle. This design reduces pressure loss and simplifies piping layouts in specific systems.
Advantages of angle type control valves...
• Compact right-angle design
• Reduced pressure drop
• Easy integration in tight spaces
• Precise flow control
• Durable and long-lasting
• Ideal for vertical flow paths
• Reduced pressure drop
• Easy integration in tight spaces
• Precise flow control
• Durable and long-lasting
• Ideal for vertical flow paths
Technical Parameters:
Pressure Ratings
PN10, PN16, PN25, PN40, PN63, PN100, CL150, CL300, CL600, CL900, CL1500, CL2500
Temperature Range
-29°C to +400°C (standard)
Up to +565°C with high-temperature materials (e.g. for steam or thermal oil)
Cryogenic options available down to -196°C
Up to +565°C with high-temperature materials (e.g. for steam or thermal oil)
Cryogenic options available down to -196°C
Size Range
DN15 to DN400 (½" to 16"); larger sizes available on request
Materials
Carbon Steel, Stainless Steel, Cast Iron, Bronze, Ductile Iron & Alloy Steel
Industry Application:
Nuclear
EFW
Oil & Gas
Power
Media Type:
Liquid
Gas
Steam
